Home
- Features
- Specification
Related Products
HiL169-SMD
P1.25｜P1.56｜P1.875
P1.25｜P1.56｜P1.875
HiL169-SMD
UHD Series 16:9 Ration Aspect Small Pitch LED Wall
Read more
H169-C
P0.625｜P0.78｜P0.93｜P1.25｜P1.56｜P1.87
P0.625｜P0.78｜P0.93｜P1.25｜P1.56｜P1.87
H169-C
R169-C Series mini filp chip technology,anti-collision, HDR picture quality.
Common cathode circuit with low power consumption. 3 in 1 integrated system.
Read more
HKC500
P1.953｜P2.6｜P2.97｜P3.91
P1.953｜P2.6｜P2.97｜P3.91
HKC500
Bendable Cabinet
Read more
HMG Series
P2｜P2.5｜P3.076｜P4｜P5｜P6.6｜P8｜P10
P2｜P2.5｜P3.076｜P4｜P5｜P6.6｜P8｜P10
HMG Series
DOOH Series LED Screen Waterproof Iron Cabinet
Read more
| Item | HiHK1000 Series | HiHK1000 Series | HiHK1000 Series | HiHK1000 Series |
| Pixel Pitch | P2.6mm | P2.97mm | P3.91mm | P4.81mm |
| LED Encapsulation | SMD1515 | SMD1515 | SMD2121 | SMD1921 |
| Scan Mode | 1/32 Scan | 1/21 Scan | 1/16 Scan | 1/13 Scan |
| Pixel Per Sq.m | 147,456 Pixel | 112,896 Pixel | 65,536 Pixel | 43,264 Pixel |
| Brightness(Nits) | 4500cd/㎡ | 4500cd/㎡ | 4500cd/㎡ | 4500cd/㎡ |
| IP Protection | IP65 | IP65 | IP65 | IP65 |
| Maintenance Method | Front/Rear Serviceable | |||
| Cabinet Material | Die Casting Aluminum | |||
| Curved Angle(0ptional) | ±15 Degrees | |||
| Module Size(W*H) | 250mm*250mm | |||
| Cabinet Size(W*H*D) | 500mm*500mm*90mm | |||
| 500*1000*90mm | ||||
| Refresh Rate | 3840Hz | |||
| Color Temperature | 9500K ±500（Adjustable） | |||
| Gray Scale | 14-16Bit | |||
| Cabinet Weight | 7KG/12KG | |||
| Usage environment | Outdoor/lndoor | |||
| Average Power Consumption | 350-400Watt/㎡ | |||
| Max Power Consumption | 800Watt/㎡ | |||
| Operating Temperature | -20°C to 50°C | |||
| Working Voltage | 100-240Volt(50-60hz) | |||
